Innovation by Nanotechnology
 |
| Place of Origin: | CHINA |
| Brand Name: | NANOLINK |
| Certification: | ISO9001 |
| Model Number: | Paint Protection Film 93-7 |
| Minimum Order Quantity: | 1 roll |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Cartons |
| Delivery Time: | 3-7DAYS |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 5000 rolls per month |
| Item: | Paint Protection Film | Feature: | Car Paint Protection |
|---|---|---|---|
| Size: | 1.52*15M | Thickness: | 8mil |
| Material: | TPU | Structure: | 5 Layer |
| Color: | Transparent | Warranty: | 5 Years |
| High Light: | automotive paint protection film,vehicle paint protection film |
||
Product Material
TPU film (thermoplastic polyurethane elastomer) material as the substrate,and precision coating nanometer repair coating and high - performance pressure sensitive adhesive coating products,both plastic and rubber excellent characteristics.
Product Structure
The product has five layers. The first layer is surface protective film, the second layer is self-repairing coating, the third layer is TPU film, the fourth layer is adhesive layer, and the fifth layer is release film.
Product Paramenters
| Testing Items | Specs | Testing Method |
| TPU thickness | 150±15 um | Idometer |
| Total thickness | 310±15um | Idometer |
| Gum | Ashland (USA) | Document |
| Release film |
One side matte release film one side pet clear 125±5um |
Idometer |
| Tensile property | 300kg/cm2 | ASTM D412 |
| Elongation | 350% | ASTM D412 |
| Glossiness | >90% | Gloss Meter @60° |
| Black paint surface | Applied on black paint surface for 10 min | |
| Light Transmittance | Clarity | Applied on trasparent acrylic sheet |
| Data | Color meter/transmittance meter | |
| Flatness | No concave, no bump | Visual |
| Peeling Property | 18~25N/inch | Peel strength tester / applied on the stainless steel sheet |
| Gum type | Methacrylate PSA | |
| Reserved Gum | No | Applied on paint panel surface |
| Oven 80°Cx24hr, refrigerated cabinet-4°Cx24hr | ||
| Scratch resistance (5pt) | 4pt | Dry towel, Brass Brush |
| Thermal Self-healing | 100% Self-healing | Dry towel, brass brush 70°C hot water |
| Chemical Resistance | no damaging within 60s | Spray CARB cleaner ( Biaobang carburetor cleaner) |
| no damaging within 60s | DMF Testing | |
| Surface Energy | 38Dyn | Dyne pen |
| Hydrophobic Property | R9-R10 | JIS P-8137 /Japan Standard JIS P-8137 |
|
Stain Resistance(normal temperature) |
Can be removed by tissue | Oil— ased marker (deli S552) |
| Stain Resistance(high) | Glossy, not sticky | Oven 80°C 1 hr. or applied on engine cover exposed for |
| Durability of coating function |
Surface energy and stain resistance no fading |
70°C hot water soaking for 12h |
| Check surface energy and stain resistance | ||
| Anti-yellowing | ΔE< 1.5 | QUV accelerated aging test (6500W) 2000h colorimeter |
| Warranty | 5years | Yellowing, existing gum, breaking surface |
Product Features
NANOLINK paint protection film products, professional used for car and other vehicles paint and interior surface protection. To reduce the car damage caused by the impact or wear of gravel, sand, and various chemicals in the harsh natural environment material damage to the finish.
Visually, if the car appears to be dinged up, rusty, scratched, worn out and rough, it will suffer from a poor resale value. Dropping your resale value by a few hundred to a grand, and weakening your selling power.
Paint protection Film can solve this problem.Buyers want original paint, and as close to perfect condition as possible. If you protect your vehicle’s paint, and keep it as close to “just off the showroom floor” as possible this gives you a selling advantage. With buyers who would be willing to pay a premium if said vehicle had good quality original paint.
Experienced R&D Department
Nanolink is backed by a strong R&D team, which is composed of creative and motivated professionals.
In the PPF market,you must have heard of XPEL,LLumar,Suntek,V-kool and so on.The majority of brand in PPF field buy from Argotec TPU film as substrate.
We imported the same TPU production equipment with Argotec and modified it to make our TPU softer and easier to install.
From granulation, powder, pulp, film, coating these processes, our company complete it on its own , and we participate in the qualitative development of raw materials.We can produce soft,clear,anti yellowing TPU film in volume.
In the next two or three years, we are the only one who owns this equipment in China.The product quality is stable and reliable, flatness reaches 3-5% level.And it reaches 8% from Japan. Our technical level and production line have reached the world's leading standards.
Our experienced R&D team can provide new product designs by manipulating science and research functions to better serve our clients and promote our products. In other words, we are able to offer the best-quality services with the most competitive prices.
The Nanolink Research and Development team works continuously to meet your future requirements.
We have two manufacturing plants, both located in Shanghai. The plants have technologically advanced laminating and coating lines, able to produce all of our PET films in-house so that we can control every aspect of quality.
We promise to deliver products timely and offer special products for meeting your exact specifications. For your assurance, chances of your next trading partner are here.
Customized Solutions
Besides our wide variety of products we are able to offer customized solutions and special developments to meet the particular demands and needs of our customers.
Shanghai NANOLINK Materials Co., LTD. Focuses on the research, development and production of thermoplastic polyurethane elastomer (TPU) films. We are committed to providing customers with high performance and high standards of product experience. Our products are widely used in traffic safety protection, display screen protection, household products protection and other fields.
Inquire Today
With our faith and innovation, we welcome all the customers around the world to visit our company and discuss business. Inquire today to get your free samples.
Our Service:
Besides our wide variety of products we are able to offer customized solutions and special developments to meet the particular demands and needs of our customers.
1) Pick you up at the airport;
2) Book hotel for you;
3) Guide you a happy trip in Shanghai.
4) Pick up you from your hotel to our yard and check our products.
>> Free Sample available on Request!
Contact Person: penny.lee
