PET Film construction window film uv 10-100% ir 10-100%
Pet Window Glass Safety Film
Filtering Ultra-Violate and leading to fading reduction help to keep brilliant colors in fabrics, furniture and flooring, etc. and protecting your skin from dangerous UV-Rays.
Reducing heat & Glare and giving comport cooling prevent full range of solor heat and light from admitting into the interior,which leads to discomfort and needs of mechanical cooling system.
Helping to maintain the clear-view & screening for privacy. Let occupants look out with clear view. While make it difficult for others to look during daytime.
DETAILS:
Colorful & performance excellence
PET base materials use three layers co-extrusion core layer coloring technology, excellent clarity
Nano inorganic carbon series super dispersion technology, elegant appearance
Three uv filters technology, super long weather resistance
Colorful, uniform color
CD FILM
Colorful & performance excellence
| Item |
Unit |
Reference Value |
Test Value |
| Average Thickness |
μm |
23 |
23±1 |
| Tensile Strength |
MD |
Kg/mm2 |
26 |
27±5 |
| |
TD |
Kg/mm2 |
24 |
26±5 |
| Elongation |
MD |
% |
127 |
140±40 |
| |
TD |
% |
110 |
130±40 |
| Heat Shrinkage |
MD |
% |
1.4 |
1.5±1 |
| |
TD |
% |
0.3 |
0±1 |
| Friction Shrinkage |
US |
- |
0.25 |
0.4±0.2 |
| |
UK |
- |
0.22 |
0.3±0.2 |
| Haze |
% |
1.5 |
≤2.0 |
| Definition |
% |
99.8 |
≥99 |
| Wetting Tension |
Dyne/cm |
52 |
≥50 |
| VLT |
% |
0-88 |
/ |
| IRR |
% |
11 |
11±2 |
| UVR |
% |
99 |
99±1 |
F&Q:
A, Technicals supports
Shanghai Nanolink Materials Co., Ltd is the corporation of the research, development and production of PET film in China. Depending on the advanced technology,equipment,high qualified PET film raw materials.
B, Raw materials guaranteed
Our producing materials of PET film is functional master batch, that is manufacturing by ourselves and we have more more years producing PET film experience.all of our raw materials are made by ourself .
company information :
Business Type: Manufacturer Supplier
Past Export Markets/Countries: China (mainland,Taiwan),the USA,Mexico,Korea
Our Service:
Besides our wide variety of products we are able to offer customized solutions and special developments to meet the particular demands and needs of our customers.
For our product we can provide you :
- Professional Free Design
- OEM Support
- Min Order Qty
- Fast Delivery
- Good after sale service
- Free Sample
- For your visiting our company we can offer you :
1) Pick you up at the airport;
2) Book hotel for you;
3) Guide you a happy trip in Shanghai.
4) Pick up you from your hotel to our yard and check our products.
>> Free Sample available on Request!
