Removable PET IR Cut Nano Ceramic Window Film For Automotive Glass UV Blocking

Removable PET IR Cut Nano Ceramic Window Film For Automotive Glass UV Blocking

    • Removable PET IR Cut Nano Ceramic Window Film For Automotive Glass UV Blocking
  • Removable PET IR Cut Nano Ceramic Window Film For Automotive Glass UV Blocking

    Product Details:

    Place of Origin: CHINA
    Brand Name: NANOLINKE
    Certification: CA SGS COA
    Model Number: IR7090

    Payment & Shipping Terms:

    Minimum Order Quantity: negotiation
    Price: negotation
    Packaging Details: pallets
    Delivery Time: 3-5weekdays after received payment
    Payment Terms: T/T,
    Supply Ability: 30t/day
    Contact Now
    Detailed Product Description
    Material: PET Use: Automotive And Building Windows
    Transparency:: High Transparency Width: 1560mm
    Length: 4000-8000m Corona: One Side
    Type: Three Layers Co-extrusion Location: Shanghai China
    Price: Competitive
    High Light:

    nano ceramic tint film

    ,

    nano ceramic solar film

    nano ceramic IR cut film automotive glass film BASE FILM



    Product Description:

    Good for both Automotive and Building windows

    High in IR blocking and heat reduced.

    Not blocking GPS or mobile network

    Protect car indoor furnishing

    Easy appply to curve windows with heat gun

    Nano ceramics film without metal



    HIGHLIGHTS



    IR Nano ceramics series for all automotive/commercial/residential; non-reflective ceramics apply on the films. IR ceramics film is a non-metalized coating film. It is known for best Infrared rejection. High in transmission for visible light, and low outer light reflection; the series could be use both for cars and buildings.



    High transparent IR FILM

    High VLT & High IR & LOW reflective

    Using nano-metal oxide dispersion and polymerization technology, different from other factories in the PET surface coated nano-ceramic .

    Put nano ceramic mixing pet make masterbatch via two –way stretch film .

    So that product performance to achieve an unprecedented stability

    Project

    Technical performance

    Test Value

    Test / calculation method

    Detective equipment



    Visible Light



    Refractive index of Visible Light

    67.33

    GB/15137.2

    Daojing UV-3600 type spectrophotometer

    Refractive index of Visible Light

    9.68

    GB/15137.2

    Daojing UV-3600 type spectrophotometer

    Solar energy

    Solar energy directly blocking rate

    56.51

    GB/2680



    Direct solar reflectance



    8.93

    GB/2680

    Daojing UV-3600 type spectrophotometer

    The total solar energy blocking rate

    45.04

    GB/2680

    Daojing

    UV-3600 type spectrophotometer

    Shading Coefficient



    0.62

    GB/2680



    UV



    UV-blocking rate



    98.68





    Thermal functional

    Haze



    GB/2680

    Shenguang WGT-S haze meter















    Item



    Unit

    Test Value

    Test method

    Tensile Strength

    MD

    Mpa

    240

    ASTM D 882

    TD

    Mpa

    264

    ASTM D 882

    Elongation

    MD

    %

    149

    ASTM D 882

    TD

    %

    132

    ASTM D 1044

    Anti-wear properties (according to standard, difference value should be before and after testing haze of sample ≦ 4%

    %

    ≦ 2%

    ASTM D 1044

    Competitive Advantages:

    1. Equipment:
    We have the most advanced Germany Bruckner Production Line

    2. Competitive price:
    We are the manufactory, all materials made by ourself .
    3. Accuracy:
    We have the strict quality control system. Good reputation in the market, ensure our products are exactly what you want.
    4. Materials:
    All cast films are made of high-quality raw materials.
    5. Certificate:Our products are certified by SGS, ISO, FDA etc.
    6. After Service:

    We can prepare all documents you need, and solve all problems related to the current order.



    Application:



    Base PET film mainly for the construction and automotive film



    Company





    Shanghai Nanolink Materials Co., Ltd is a high-technology enterprise, which has nanometer materials preparation, grinding scattering, modified function of masterbatch as core technology, is based on the research and development of functional materials from optical PET film, and integrates the technology of functional masterbatch dispersion, aggregation, BOPET and online surface coating.
    In the foreseeable future, Nanolink will use its own advanced technology and intellectual property rights, integrate the world's leading expert team, and continue to invest in the existing and future advanced technology, in order to realize the development goals and look forward to more breakthrough in the film industry in the near future.
    Core products of Nanolink current : PET Chip Dyed Film, high blocked UV film, color electronic tape of base film , carbon black (kaben series) constant color of base film, etc.



    Our Service:

    Besides our wide variety of products we are able to offer customized solutions and special developments to meet the particular demands and needs of our customers.

    1. For our product we can provide you :

    1. Professional Free Design

    2. OEM Support

    3. Min Order Qty

    4. Fast Delivery

    5. Good after sale service

    6. Free Sample

    1. For your visiting our company we can offer you :

    1) Pick you up at the airport;

    2) Book hotel for you;

    3) Guide you a happy trip in Shanghai.

    4) Pick up you from your hotel to our yard and check our products.
